RSF115
Rotatable scale flowmeter, max. flow rate 30 SCFM (900 SLPM) air, 5 GPM (20 LPM) water.
Choose a Variant
Mounting Orientation
Valve Type
Material Construction Option
Added to Your Shopping Cart
Configuration complete.
Please add to cart to keep it or exit the configuration
Please add to cart to keep it or exit the configuration
Failed to Save Configurations, Click on Configure Button Start Again
Product Specs
<< See all Product Models| Brand |
 |
| Accuracy | ± 7 % |
| Gas Flow, Max | 30 SCFM |
| GrossWeightValue | 2.74 |
| Liquid Flow, Max | 5 GPM |
| Material Construction Option | Stainless Steel |
| Measurement Pressure Type | Gauge |
| Mounting Orientation | Vertical |
| Operating Temperature, Max | 250 °F |
| Process Connection Note | Two 3/8˝ female NPT |
| Process Connection Size | 3/8 in |
| Process Connection Type | NPT Female |
| Proof Pressure | Up to 150 psi |
| Repeatability | ± 0.25% |
| Scale Length | 127 mm |
| Series ID | Series-RSF |
| Turndown Ratio | 10:1 |
| Valve Type | N/A |
| Country of Origin | United States |
| See All Specs | |
PDFs & Manuals
Drawings
Accessories
NIST traceable calibration certificate for variable area flowmeters (air). NOTE: EQUAL CERTS WILL BE CHARGED PER UNITS PURCHASED.
$496.44 / each
0 In Stock
NIST traceable calibration certificate for variable area flowmeters (water). NOTE: EQUAL CERTS WILL BE CHARGED PER UNITS PURCHASED.
$392.20 / each
0 In Stock
