RH-Outdoor-Air
Relative Humidity Outdoor Air
- Monitor Outdoor Air Humidity
- Economizer Control
- Psychrometric calculations such as Enthalpy and Dew point
- Wash down Applications
RH-Outdoor-Air
From
$
406.00
Product Overview
- Applications Environmental Monitoring, Fluid Measurement and Control
- Electrical Connection Screw Terminal
- Electrical Output 4 to 20 mA
- Filter Hydrophobic Filter
- Current, Max 8 mA
- Measurement Type Humidity, Temperature
- Mounting Orientation Outdoor Air
- Operating Temperature, Max 60 °C
- Operating Temperature, Min -40 °C
- Output Detail 0-5 VDC: 12 - 40 VDC / 18 - 28 VAC
- Relative Humidity 10 to 95%
- Relative Humidity Sensor Type Capacitive with Hydrophobic Filter
- Repeatability 0.5% RH,± 0.05°C
- Response Time 20 Seconds Typical
- Sensitivity 0.1% RH
- Series ID RH-Outdoor-Air
- Stability RH Stability: Less than 2% drift / 5 years
- Storage Temperature, Max 65 °C
- Storage Temperature, Min -40 °C
- Supply Power Type DC
- Supply Voltage 24 Vdc
- Tightening Torque 4.43 to 5.31 lb-in (0.5 to 0.6 Nm)
- Wire Gauge 26 to 16 AWG
