RD-VRF
RD-VRF
- 10-year sensor life
- Digital Output: Modbus (STD), BACnet (optional)
- Easy installation to double gang box or 4x4 electrical box
- Same model provides either 24V or 120V options
- Internal display for programming/testing
- Multicolor LED status indicator
- Made in America
Product Overview
- Alarm Indication RGM LED, Audible Alarm
- Alarm Note Features 2 alarm levels (1,000 & 2,000 PPM), audible buzzer (75 dBA at 10 ft), and multicolor LED status indicator. Includes two SPDT (Form C) relays for local notification or building management system integration.
- Applications Air, Air and HVAC, Clean Rooms, Laboratories, Medical, Office and Commercial, Residential, School Buildings & Dormitories
- Audible Alarm 75 dBA @ 10 ft
- Calibration Interval 12_months
- Calibration Note Recommend calibration yearly; features a built-in cal-port for maintenance.
- Control Output 2 SPDT Relay
- Data Logging No
- Height 5.157 in
- Operating Temperature, Max 122 °F
- Operating Temperature, Min 14 °F
- Overall Depth 1.861 in
- Programming internal display
- Sensor Life 10 years
- Sensor Replaceable Yes
- Sensor Type NDIR
- Series ID Series-RD-VRF
- Supply Power Note Same model provides either 24V or 120V options
- Supply Power Type Electric
- Width 5.088 in
The Macurco RD-VRF Refrigerant Gas Detector is designed to provide continuous refrigerant monitoring in VRF (Variable Refrigerant Flow) applications.
