Outdoor Horn & Strobe
- 12-48 VDC or 24-48 VAC
- NEMA 4X
- IP66 Rated
- Polycarbonate Enclosure
- Selectable Color LED
- Selectable visual signaling modes
- Selectable audio tones
- Sound adjustable
- Various Mounting Configurations
Series-Outdoor-Horn-and-Strobe
From
$
515.00
Product Overview
- Additional Features Selectable visual signaling modes.Selectable audio tones.Sound adjustable.Various Mounting Configurations
- Alarm Indication Multi-colored LED, Audible Alarm
- Alarm Note Selectable LED colors, multiple visual signaling modes (flash, blink, continuous, rotate), and over 70 alarm tone combinations with adjustable sound levels and 4 externally selectable tones.
- Applications Control Panel, Process Automation and Control
- Audible Alarm 105 dBA
- Compatibility Compatible with Macurco control panels and 6 & 12 Series detectors.
- Compliance Note UL Listed Type 1, 2, 3, 3R, 4/4X, 12, 13
- Conduit Connection 1/2 in NPT
- Conduit Connection 20mm (top and bottom access
- Electrical Rating Note Enclosure Rating=NEMA 4/4X, 12, 13, Type 1, 2, 3, 3R; IP Rating=IP66 (EN 60529); Impact Resistance=IK 07 (EN 50102)
- Enclosure Material Polycarbonate
- Enclosure Ratings IP66, NEMA Type 4X
- Finishing White
- Height 3.5 in
- Mounting Wall mount (conduit connection: ½″ NPT; 20mm, top and bottom access)
- Mounting Note 1/2” NPT, 20mm conduit connection via top and bottom access; accepts AWG 22-12 CU wiring.
- Operating Environment -13°F to 122°F (-25°C to 50°C); 0% to 95% RH non-condensing; IP66; NEMA 4/4X; IK07; UL Type 1, 2, 3, 3R, 4/4X, 12, 13
- Operating Humidity 0 to 90% RH, non-condensing
- Operating Temperature, Max 122 °F
- Operating Temperature, Min -13 °F
- Overall Depth 3.3 in
- Programming internally and externally selectable (via settings and jumpers)
- Series ID Series-Outdoor-Horn-and-Strobe
- Sound Level Note Over 70 tone combinations with adjustable sound levels; sound level reduction of -7 dB, -13 dB, or -20 dB available.
- Sound Output 105 dB(A) (70 Tones)
- Supply Power Type Electric
- Supply Voltage 12 to 48 Vdc, 24 to 48 Vac
- Supported Devices Macurco control panels and 6 & 12 Series detectors
- Width 4.6 in
- Wire Gauge Note AWG 22-12 CU
The Macurco Outdoor-Rated Multi-Colored LED Horn & Strobe is a highly versatile notification appliance designed for reliable performance in demanding environments. Housed in a rugged NEMA 4X/IP66 polycarbonate enclosure, this low-voltage device delivers both audible and visual alerts with customizable signaling options. With selectable LED colors, multiple light modes (flash, blink, continuous, rotate), and over 70 tone combinations with adjustable sound levels, the unit adapts seamlessly to a wide range of safety applications. Fully compatible with Macurco control panels and 6 & 12 Series detectors, it offers flexible mounting configurations and dependable operation for critical gas detection and alarm systems.
