Series-LF601

Supported Applications

The Weiss Series LF601 consists of liquid-filled and leakproof pressure gauges designed for analog pressure indication. As part of the DwyerOmega portfolio under the category path DwyerOmega | Pressure | Gauges & Manometers | Pressure Gauges, this series provides visual monitoring solutions where vibration damping or process isolation is required.

Operating Conditions & Performance

The Series LF601 operates as a liquid-filled gauge, utilizing internal fill fluid to dampen needle movement and protect the mechanism from pulsation. The leakproof design ensures containment of the fill fluid within the instrument housing. Specific performance metrics such as accuracy class, overpressure limits, ambient temperature ranges, or response times are not provided in the current documentation bundle.

Documented Pressure Ranges

The available variants indicate a range of pressure scales supported by the series:

• Liquid-filled configurations: Models LF601-015, LF601-030, LF601-060, LF601-100, LF601-160, LF601-200, and LF601-300.
• Higher range configuration: Model LF601-400.

Note: The numeric suffixes in the part numbers (e.g., 015, 030) correspond to specific pressure ranges or scale configurations as defined by Weiss model nomenclature. Exact unit values and range limits are not specified in this bundle.

Configuration Options

The Series LF601 is offered with a liquid-filled construction across all listed variants, indicated by the "4L" suffix common to every SKU (e.g., LF601-015-4L). This designation confirms the presence of fill fluid in each unit.

Available Model Configurations

The series includes nine enabled variants covering different pressure scale requirements:

• Liquid-filled models (Standard): LF601-015-4L, LF601-030-4L, LF601-060-4L, LF601-100-4L, LF601-160-4L, LF601-200-4L.
• Liquid-filled models (Extended): LF601-300-4L, LF601-400-4L.
• Vacuum/Compound model: LF601-V60-4L.

The "V" prefix in the variant LF601-V60-4L indicates a vacuum or compound pressure capability distinct from the positive-pressure-only models. Specific details regarding process connections, wetted materials, housing dimensions, or dial sizes are not available in this bundle.

Key Product Differences

The primary distinction within the Series LF601 is the pressure range and scale type represented by the numeric suffixes (e.g., 015 through 400) and the "V" designation for vacuum applications. All variants share the liquid-filled, leakproof construction feature.

Model Differentiation

• Numeric Suffix: Indicates specific pressure scale ranges (e.g., -015-, -400-). The exact psi or bar values for these scales are not listed in the current data.
• Vacuum Option: The model LF601-V60-4L is differentiated by its ability to measure vacuum, as indicated by the "V" prefix.

No additional variations regarding output signals (e.g., electrical switches), display types, or special certifications are documented in this bundle. Selection among variants depends on matching the required pressure scale and measurement type (positive vs. compound/vacuum) to the specific application needs.
