Model-DL-8T
8-Channel Temp Logger, Internal Sensor, 7 External Thermocouples, 12-Bit
Model-DL-8T
From
$
2,678.05
Product Overview
- Applications Environmental Monitoring, Industrial and Manufacturing
- Battery Size and Type 3.6V Li-ion
- Clock Accuracy ± 8 s/day plus one sampling interval
- Compensated Temperature, Max 158 °F
- Compensated Temperature, Min -40 °F
- Compliance CE
- Electrical Connection Screw Terminal
- Materials Plastic
- Memory 1,048,000 Readings
- Number of Channels 8
- Operating Temperature, Max 160 °F
- Operating Temperature, Min -50 °F
- Relative Humidity 0 to 95%, Non-Condensing
- Resolution 12 bit
- Sensor Type One internal thermistor and seven for External Thermocouple
- Stop Modes Adjustable Logging Intervales
- Supply Power Note 3.6V Lithium Battery, Built-in
- Supply Power Type Battery
- System Requirements IBM compatible running Windows® 3.1, Windows® 95, Windows® 98, Windows® 2000, Windows® ME, Windows® NT, or Windows® XP
- Temperature Accuracy ± 1%
- Weight 5 oz
Monitor and record temperature in eight different locations with the Model DL-8T Temperature Logger. The DL-8T has a built-in sensor for local temperature monitoring and accepts seven external thermocouples in types J, K, T, S, or E. The unit features 12-bit resolution for greater accu- racy and more precise measurements. The DL-8T is self-powered by a long-life lithium battery that will provide years of reliable operation. Quick- ly configure the logger using the Windows® software (sold separately). The DL-8T can store over a million readings with up to 25 samples per second. The stored data can be remotely accessed using a modem. The logger is network capable and can be programmed for alarm dial- out.
