DBCL130-Series
-25 °C to +130 °C Temperature Dry Block Calibrator
Models In Stock
- Maximum temperature of 130°C / 266°F
- Minimum temperature of -25°C / -13°F
- Up to eight setpoints can be stored & recalled
- Insert well & ¼” diameter reference well
DBCL130-Series
From
C$
7,422.76
Models In Stock
Product Overview
- Status Control false
- Accuracy ± 0.4 °C
- Accuracy Detail ±0.4°C (-20 to 130°C) ±0.7°F (-4 to 266°F)
- Cool-Down Time Note Cool down 20 to -20°C: 3 minutes (ambient of +20°C) Cool down 130 to 20°C: 2.5 minutes
- Data Interface N/A
- Dimensions Note 11 x 9 x 8 inches/279 x 229 x 203 mm *excluding the carrying strap
- Display Resolution 0.1°
- Frequency 50/60 Hz
- Heat-Up Time Note Heat up time -20 to 130°C: 5 minutes Heat up time 20 to 100°C: 2 minutes
- Operating Temperature, Max 40 °C
- Operating Temperature, Min 5 °C
- Process Temperature Note -25°C/-13°F to 130°C/266°F at an ambient of 20°C/68°F
- Relative Humidity, Max 0.95
- Relative Humidity Note Up to 95% relative humidity, non-condensing
- Temperature Overload Protection Fan Cooling: Automatic
- Temperature Stability ±0.050°C(10 minutes)
- Well Type N/A
The DBCL-130 calibrator provides a safe, dry, constant temperature source for checking and calibrating a wide range of temperature sensors, systems, indicators and thermometers. It is fast and economical and can be used either on a bench top or as a portable field unit. The weight of the unit is only 15 pounds/6.8 kilograms. The unit covers the temperature range from -25 °C to +130 °C in an ambient of 20 °C using a machined aluminum block as the heat transfer medium. The temperature control circuit is built into the unit.
Accessories
Show Ratings & Reviews
Is there a uniformity specification?
Hi Ronboom
Thank you for the inquiry. We do not have a uniformity spec on this product. The sensors should be inserted to the full depth of the well to achieve stated accuracy. All wells meet the stated accuracy spec.
Best regards
OMEGA
Date published: 2021-07-20
