Product Specs
<< See all Product Models| Brand |
 |
| Electrical Connection | Screw Terminal |
| Materials, Wetted | Consult Factory |
| Measurement Pressure Type | Differential |
| Media Compatibility | Clean dry air / inert gas, Fuel gases, HVAC / room air, Inert / non-reactive gases, Combustible Gases, Helium, Hydrogen, Methane, Nitrogen, Non-Corrosive Dry Gases, Propane, Propane |
| Mounting Orientation | Vertical Diaphragm |
| Operating Temperature, Max | 140 °F |
| Operating Temperature, Min | 0 °F |
| Process Connection Size | 1/8 in |
| Process Connection Type | NPT Female |
| Proof Pressure | Up to 45 inH2O |
| Series ID | Series-1950G |
| Set Point Adjustment | External Screw |
| Switch Note | 1 form C relay (SPDT), 10 A, 120/240 VAC, 28 VDC. Resistive 50 mA, 125 VDC |
| Switch Rating | 10 A @ 120/240 Vac/28 Vdc; 50 mA @ 125 Vdc |
| Switch Type | SPDT NO/NC, Selectable |
| Weight | 1.35 kg |
| See All Specs | |
