Series-476A

Manomètre différentiel numérique, -20 à 20 inH2O, ± 1,5 % FS, Aluminium

(0)

Modèles en stock

± 0.5% full-scale accuracy
Rugged extruded aluminum housing
One button auto-zero function
Auto power off function to conserve battery life
Instant selection of up to nine English/metric units

Voir l'aperçu du produit

Series-476A

Depuis ^C$ 275.09

Modèles en stock

Modèles de boutique

3 variantes disponibles

Voir toutes les options de séries ci-dessous

Fiche technique

L'aperçu du produit

Précision ± 1.5 %
Détail de la précision ± 1.5% FS at 72°F (22.2°C). Includes linearity and repeatability
Battery Size and Type Alkaline 9V
Compensated Temperature, Max 104 °F
Compensated Temperature, Min 32 °F
Display Note 4 digit LCD (.425˝H x .234˝W digits)
Display Type LCD
Hysteresis ± 0.1%
Kit None included
Materials, Wetted Consult Factory
Measurement Type Pressure
Media Compatibility Clean dry air / inert gas, HVAC / room air, Inert / non-reactive gases, Nitrogen
Number of Digits 4
Operating Temperature, Max 140 °F
Operating Temperature, Min 0 °F
Pressure Limits Up to 5 psi
Supply Power Type Battery
Thermal Effects 0.05% FS/°F
Weight 10.8 oz

The Series 476A Single Pressure Differential Pressure Digital Manometer can be used to measure low pressures from -20 to 20 in w.c. with ±1.5% FS accuracy.
The Series 478A Single Pressure Differential Pressure Digital Manometer can be used to measure positive, negative, or differential pressures with ±1.5% full-scale accuracy. Both units are constructed of an extruded aluminum case for exceptional durability.

NIST CALIBRATION available in Product Configurator.
