An accelerometer is a device that measures the vibration or acceleration of motion of a structure. The force caused by vibration or a change in motion causes an internal mass to compress a piezoelectric material, which produces an electrical charge proportional to the force exerted on it. Because the charge is proportional to the force and the mass is constant, the resulting signal is also proportional to acceleration.
Accelerometers are used in a wide range of applications, from space stations to handheld devices. Most modern smartphones contain an accelerometer that detects changes in orientation and motion, allowing the phone to recognize movement and adjust functions such as screen rotation.
In industrial environments, accelerometers help engineers evaluate machine stability and monitor unwanted forces or vibration that could indicate developing mechanical issues.
Innovative Solutions from DwyerOmega
How Does an Accelerometer Work?
Accelerometers operate using electromechanical sensing elements designed to measure either static acceleration or dynamic acceleration.
Static Acceleration
Static acceleration refers to constant forces acting on an object, such as gravity or friction. These forces remain relatively uniform and predictable.
The acceleration caused by gravity is approximately 9.8 m/s², which is nearly constant across the surface of the Earth. Accelerometers can detect this steady acceleration and use it to determine orientation or tilt.
Dynamic Acceleration
Dynamic acceleration refers to non-uniform forces that occur due to motion changes such as vibration, shock, or impact.
During a car crash, acceleration changes rapidly compared to the previous state of motion. Accelerometers detect these rapid changes and convert them into measurable electrical signals.
Types of Accelerometers
Several types of accelerometers exist, each operating according to a different sensing principle.
Piezoelectric Accelerometers
Piezoelectric accelerometers generate an electrical signal when the sensor experiences acceleration.
These devices contain a sensing crystal attached to a seismic mass. When acceleration occurs, the mass applies force to the crystal. The piezoelectric crystal converts this force into an electrical charge that can be measured to determine acceleration.
Piezoelectric accelerometers are highly effective for measuring shock and vibration.
Piezoresistive Accelerometers
Piezoresistive accelerometers operate by changing electrical resistance in response to acceleration.
When acceleration occurs, mechanical stress alters the resistance of the sensing element. This resistance change can be measured to determine the rate of acceleration experienced by the sensor.
Piezoresistive accelerometers are generally less sensitive than piezoelectric designs and are not ideal for low-frequency impacts. However, they perform well at high amplitudes and are commonly used in vehicle crash testing and weapons testing.
Capacitive Accelerometers
Capacitive accelerometers measure acceleration by detecting changes in capacitance.
These sensors typically contain two capacitive plates separated by a diaphragm. When acceleration occurs, the diaphragm moves, altering the distance between the plates. This change affects capacitance, which can be measured and converted into an acceleration value.
Capacitive MEMS (microelectromechanical system) accelerometers are commonly used in consumer electronics, including smartphones.
Triaxial Accelerometers
A triaxial accelerometer measures acceleration in three orthogonal directions: X, Y, and Z.
These sensors contain three sensing elements arranged perpendicular to one another. This configuration allows the device to measure vibration or motion in all three spatial dimensions simultaneously.
Triaxial accelerometers are commonly used in applications such as:
- Structural vibration monitoring
- Turbine monitoring
- High-speed rotating machinery
Common Applications of Accelerometers
Accelerometers are widely used across industrial, commercial, and laboratory environments.
Digital Devices
Smartphones, digital cameras, and other mobile electronics use accelerometers to detect orientation and automatically rotate displays.
Vehicles
Accelerometers play a critical role in automotive safety systems. In airbag systems, sensors detect sudden deceleration during a collision and send a signal that triggers airbag deployment.
Drones
Accelerometers help stabilize drones during flight by monitoring motion and orientation.
Rotating Machinery
Accelerometers installed on rotating machines to detect abnormal vibration patterns that may indicate imbalance, wear, or mechanical failure.
Industrial Platforms
Industrial accelerometers are used to measure platform stability or detect tilt in equipment and structures.
Vibration Monitoring
Machines that move or rotate generate vibration. If these vibrations increase beyond acceptable limits, they can damage equipment. Accelerometers are commonly used in industrial plants and turbine systems to monitor vibration levels and help identify potential issues before failure occurs.
