Model-MN-1
Mini-Node™ RS-485 to USB Converter - Compact & USB-Powered Model MN-1
- Converts half-duplex RS-485 via USB port
- Reduces set up time of process controllers
Product Overview
- Baud Rate 75 to 115200
- Compatibility Full compliance with USB V.2.0 specification
- Compliance CE
- Impedance 96 kΩ
- Input Type RS-485
- Isolated Analog Voltage 3000 Vdc
- Power Consumption 0.4 W
- Supply Power Type DC/USB
- USB Type Type B
The Model MN-1 Mini-Node™ Communication Signal Converter is a low-cost device that converts half-duplex RS-485 serial communications signals into a signal that can be read by any computer with a USB port. The integral USB connector and RJ-45 connector reduces setup time by eliminating extra wiring. The Model MN-1 is powered via the USB connection which eliminates the need for an external power source. The compact size is great for field installation, control panels, and lab testing.
Product Applications
- Oven, boiler, or chiller control
- Hot plates/melt pots
- Packaging equipment
- Environmental chambers
- Medical equipment
- Food service equipment
