HHG1394-EMF-Test
Data Logging Three Axis Electromagnetic Field Tester, Gauss Meter
Models In Stock
HHG1394-EMF-Test
From
$
640.86
Models In Stock
Product Overview
- Status Control false
- Auto Power Off Approximately 15 minutes
- Bandwidth 30 to 2000 Hz
- Battery life 100 hr
- Battery Size and Type Alkaline AAA
- Data Interface USB
- Display Measuring Units Gauss, Tesla
- Display Range 20/200/2000 mG, 2/20/200 µT
- Display Resolution 0.01/0.1/1 mG or 0.001/0.010/0.1 uT
- Display Type LCD
- Height 150 mm
- Length 38 mm
- Memory 2000 data sets (manual and continuous mode)
- Number of Batteries 6
- Operating Humidity 0 to 80% RH
- Operating Temperature, Max 50 °C
- Operating Temperature, Min 0 °C
- Storage Humidity, Max < 70 % RH
- Storage Temperature, Max 60 °C
- Storage Temperature, Min -10 °C
- Weight 165 g
- Width 74 mm
PDFs & Manuals
Show Ratings & Reviews
Rated 5 out of
5
by
magfinder from
great tool
so far I am happy with this tool, easy to use, nice display
Date published: 2018-04-09
Do you have a version for remote monitoring that is powered by external power source not batteries. Also can this be mounted next to a solar array outside of a weather protection box? Maybe install inside a plastic box (obviously not in a metal box)?
Omega does not have any Gauss meters that are powered with an external source. You can locate the meter outside in a protected enclosure that does not inhibit the magnetic field and keeps the meter within it's ambient operating environment.
Date published: 2023-08-26
