F7-LL

Vertical level switch, polysulfone float, Buna-N stem, temperature limit 180°F (82°C), pressure limit 50 psig (3 bar), electrical rating 20 VA: 0.08A @ 240 VAC, 22 AWG 72" (182 cm) wire leads, 1/8" male NPT mounting, weight 2 oz (58 g).

5.0
(2)
Vertical level switch, polysulfone float, Buna-N stem, temperature limit 180°F (82°C), pressure limit 50 psig (3 bar), electrical rating 20 VA: 0.08A @ 240 VAC, 22 AWG 72" (182 cm) wire leads, 1/8" male NPT mounting, weight 2 oz (58 g).
Click and hold to zoom
See all Models See all accessories

$158.35 / each

Item# F7-LL

In Stock

Lead Time (If not in stock): 10 weeks
+ Add to Project List
See Specs

Product Specs

<< See all Product Models
Brand
Cable Material N/A
GrossWeightValue 0.1
Material Construction Option Polysulfone Float
Materials, Wetted Buna-N (NBR), Polysulfone
Measurement Pressure Type Gauge
Mounting Vertical
Mounting Orientation Vertical
Operating Temperature, Max 180 °F
Process Connection Size 1/8 in
Process Connection Type NPT Male
Proof Pressure Up to 50 psi
Series ID Series-F6-F7-Horizontal
Switch Rating 30 VA: 0.14 A @ 220 Vac
Switch Type SPST
Weight 2 oz
Wire Gauge 18 AWG
Country of Origin United States
See All Specs Show Less
Vertical level switch, polysulfone float, Buna-N stem, temperature limit 180°F (82°C), pressure limit 50 psig (3 bar), electrical rating 20 VA: 0.08A @ 240 VAC, 22 AWG 72" (182 cm) wire leads, 1/8" male NPT mounting, weight 2 oz (58 g). F7-LL F7-LL
